GJL36030M04 - Square D - Molded Case Circuit Breakers
Overview
Product Specifications - GJL36030M04 - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
GJL36030M04 -
Manufacturer:
-
Family:
GJL Series -
Pole:
3 -
Amp
30 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
Feed-Thru -
Type:
GJL -
Functions:
I - Instantaneous -
Protection:
Magnetic Only -
AIC Ratings:
65kA@480V
Dimensions
-
Dimensions (HxWxD):
3.54 x 3.94 x 4.72 -
Weight:
‎2.21 lb
Standards
Product Description - GJL36030M04 - Schneider Electric Molded Case Circuit Breakers
Dive into the GJL36030M04 by Square D, a 3-phase (3P) molded case circuit breaker from the GJL Series. With a 30A rating at 600V, it is UL listed and features a high interrupting capacity of 65kA@480V. Tailored for Feed-Thru applications, it provides I - Instantaneous protection only. Equipped with line & load side lug terminals, Mag-Gard MCP, and a magnetic range of 90-330A, this is a Magnetic-Only molded case circuit breaker.
