HJL36060U43X - Square D - Molded Case Circuit Breakers
Overview
Product Specifications - HJL36060U43X - Schneider Electric Molded Case Circuit Breakers
-
Part Number:
HJL36060U43X -
Manufacturer:
-
Family:
Powerpact -
Pole:
3 -
Amp
60 -
Volt:
600 -
Phase:
3
-
Category:
-
Connection:
Feed-Thru -
Type:
H Frame -
Functions:
LSI - Long-Time, Short-Time and Instantaneous -
Protection:
Solid State -
AIC Ratings:
65kA@480V
Dimensions
-
Dimensions (HxWxD):
3.39 x 4.09 x 6.42 -
Weight:
4.85 lb
Standards
Product Description - HJL36060U43X - Schneider Electric Molded Case Circuit Breakers
Elevate your electrical system with the HJL36060U43X molded case circuit breaker from Square D's Powerpact series. This 3-phase, 60A solution, configured for ABC phase connection, is designed for a voltage of 600V, with a current-limiting feature and an impressive interrupting capacity of 65kA@480V. UL-listed and suitable for reverse fed applications, the breaker comes complete with a micrologic ammeter non-interchangeable trip with LSI (Long-Time, Short-Time, Instantaneous) trip functions and line & load side lug terminals. It operates on Solid State electronic technology for precise circuit control.
